25mm 32mm 40mm 50mm Customized Packing Polyester Cargo Webbing Lashing Strap Belts Lifting for Transportation Cargo Control
High-strength polyester cord woven one way lashing strap (25–75mm), superior to steel strapping.
Heavy-duty, weather & chemical resistant, supports logo printing.
Ideal for transportation and cargo securing with breaking strength up to 12,500daN.
Specification
| Item Code | Width | Lin. Breaking strength ±10%(kg,lbs) | Meter/ft/coil | Coils/box | Coils/pallet |
|---|---|---|---|---|---|
| TW40L | 13mm 1/2″ | 295kg/650lbs | 1200M/3937ft | 3 | 108 |
| TW50L | 16mm 5/8″ | 350kg/771lbs | 850M/2789ft | 3 | 108 |
| TW60L | 19mm 3/4″ | 430kg/947lbs | 700M/2297ft | 3 | 108 |
| TW40 | 13mm 1/2″ | 375kg/826lbs | 1100M/3609ft | 3 | 108 |
| TW50 | 16mm 5/8″ | 450kg/992lbs | 850M/2789ft | 3 | 108 |
| TW60 | 19mm 3/4″ | 580kg/1279lbs | 600M/2000ft | 3 | 108 |
| TW65 | 19mm 3/4″ | 750kg/1653lbs | 500M/1640ft | 3 | 108 |
| TW66 | 19mm 3/4″ | 818kg/1804lbs | 500M/1640ft | 3 | 108 |
| TW85 | 25mm 1″ | 1000kg/2200lbs | 500M/1640ft | 3 | 108 |
| TW86-1200 | 25mm 1″ | 1230kg/2700lbs | 500M/1640ft | 3 | 108 |
| TW105AAR | 32mm 1-1/4″ | 1500kg/3285lbs | 335M/1100ft | 3 | 108 |
| TW150AAR | 38mm 1-1/2″ | 2455kg/5400lbs | 180M(600ft)/roll in ribbon wound | 4 | 192 |
| TW55 | 16mm 5/8″ | 600kg/1322lbs | 600M/2000ft | 3 | 108 |
| TW56 | 16mm 5/8″ | 818kg/1800lbs | 600M/2000ft | 3 | 108 |
| TW74 | 19mm 3/4″ | 1000kg/2200lbs | 500M/1640ft | 3 | 108 |
| TW75 | 19mm 3/4″ | 1100kg/2400lbs | 500M/1640ft | 3 | 108 |
| TW76 | 19mm 3/4″ | 1227kg/2700lbs | 500M/1640ft | 3 | 108 |
| TW86-1350 | 25mm 1″ | 1365kg/3000lbs | 400M/1300ft | 3 | 108 |
| TW105H | 32mm 1-1/4″ | 2300kg/5000lbs | 125M/410ft | 4 | 192 |
| TW150HAAR | 38mm 1-1/2″ | 3500kg/7700lbs | 180M(600ft)/coil 100M/roll in ribbon wound | 4 | 192 |
| TW200AAR | 40mm 1-5/8″ | 5000kg/11000lbs | 100M/328ft | 4 | 192 |
| TW500 | 50mm 2″ | 5000kg/11000lbs | 100M/328ft | 4 | 192 |
| TW750AAR | 50mm 2″ | 7500kg/16500lbs | 75M/250ft | 4 | 192 |
SUPERIOR TO STAINLESS STEEL
HEAVY DUTY VIRGIN WOVEN POLY
CONFORMS TO ODD &STANDARD SHAPES
EASY & EFFICIENT TO WORK WITH
HEAVY DUTY & CRAZY PROTECTIVE
Specification
|
Item name
|
25-50MM Polyester Cord Woven One Way Lashing Strap
|
|
Material
|
Polyester
|
|
Color
|
White/Yellow/Orange
|
|
Min System Breaking Strength
|
3400-12500daN
|
|
Logo Printing
|
Support
|
Additional Information
Manufactured in accordance and the essential requirements of the European Machinery Directive.
The most popular size and most frequently used is 50mm wide webbing with a lashing capacity of 2500 daN&2000daN. STF(Standard Tension Force) could be over 350daN.
Polyester webbing is unaffected by weather, oils, grease and most chemicals, although contact with strong alkalis should be avoided.
In webbing width from 25mm to 75mm
